Main Features
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Certified safety CE requirements.
Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.
Large digital white-digit display with humidity selection button (3 preset level), internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Electrolux Professional Fridge Control APP make the life easier for our customers: - Monitor safety of preservation process thanks to HACCP data & alarms for precise control- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address- Quick operations: set the cabinet temperature/humidity/turbocooling and set date/hour
Equipped with Optiflow forced air circulation system for rapid cooling and temperature distribution within the cell.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Fully removable cooling unit to facilitate maintenance.
Frontal and easy access to all components in the cooling unit.
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Anti-tilt runners accept GN 1/1 containers.
Tropicalized unit.
Self closing stainless steel doors (< 90°).
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Hot gas automatic evaporation of defrost water.
Sustainability
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Frost Watch Control starts automatically the defrosting process only when needed and ends once ice is melted, improving energy efficiency results.
Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3) - CFC and HCFC free.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Construction
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Internal dimension of the drawers.
• models with 2 1/2 drawers: 1st drawer (top drawer) 203x302x521 / 2nd drawer 223x302x521 (HxWxD)
• models with 3 1/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd and 3rd drawers 118x302x521 (HxWxD)
• models with 1/3+2/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd drawer 333x302x521 (HxWxD)
Interior base with rounded corners, pressed from a single sheet.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
External bottom panel in stainless steel.
External back panel in galvanized steel.
Built-in refrigeration unit.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Mounted on Stainless steel legs to give 150 mm clearance for ease of cleaning the floor.
