ecostore HPe 1 Door Digital Refrigerator, 670lt (-2/+10), AISI 304 R290 - Class A (COD 725457)
Where to buy
ecostore HPe1 Door Digital Refrigerator, 670lt (-2/+10), AISI 304 R290 - Class A
ecostore HPe 670 liters Digital Refrigerators (R290)

ecostore HPe
1 Door Digital Refrigerator, 670lt (-2/+10), AISI 304 R290 - Class A

COD 725457

1-door Refrigerator 670lt, -2+10°C, digital, AISI 304, R290, Class A

Suggested green version.

Where to buy
Register your product

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.19 kW

  • Gross capacity: 670 lt

    Net Volume: 503 lt

    N° of doors: 1

    Door hinges: Right Side

    External dimensions, Width: 740 mm

    External dimensions, Depth: 860 mm

    External dimensions, Depth with Doors Open: 1480 mm

    External dimensions, Height: 2080 mm

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Internal panels material: 304 AISI

    Number of positions & pitch: 44; 30 mm

  • Energy Class (EU Reg. 2015/1094): A

    Yearly and daily energy consumption (EU Reg. 2015/1094): 340kWh/year - 1kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 23.69

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 359 W

    Refrigerant weight: 110 g

  • Number and type of grids (included): 3 - GN 2/1

  • Control type: Digital

    Compressor power: 1/4 hp

    Refrigeration power at evaporation temperature: -10 °C

    Min/Max internal humidity: 70/90

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Operating mode: Ventilated

    Cooling unit: Built-In

    Defrost type: Electric

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Product Features

Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Internal structure with numerous charging positions available to host grids, ensuring higher net capacity and a greater storage space.
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Rilsan coated grids for improved protection.
Optimized back to front forced air flow provide even temperature distribution and fast cooling in any conditions.
Tropicalized unit.
Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.
Automatic defrost.
Easy serviceability thanks to the intuitive control panel with access via app.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
Equipped with single phase electrical cable and Schuko plug for easy and fast installation.
Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.
Right hinged full door.
Easy access to the main components for maintenance.
Constructed from the highest quality AISI 304 Stainless steel.
Stainless steel runners and supports easily disassembled.
Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Doors are self-closing and can be fully opened up to 180°.
Lockable door.
The rounded internal corners, the easily removable runners and grids allow for ease of cleaning and high hygiene standards.
Mounted on adjustable Stainless steel feet, with castors as an option.

Included Accessories

Quantity
Code
Description
Quantity: 3
Code: 881020
2/1GN grey rilsan grid with 2 runners
