Digital Undercounter Compact Refrigerated Counter - 250lt, 2 Doors (R290) (COD 725109)
Where to buy
Digital UndercounterCompact Refrigerated Counter - 250lt, 2 Doors (R290)
Compact refrigerated counters

Digital Undercounter
Compact Refrigerated Counter - 250lt, 2 Doors (R290)

COD 725109

2-door compact Refrigerated Counter 250lt, +2+10°C, AISI 304

Where to buy
Register your product

Specifications

  • Built-in Compressor and Refrigeration Unit

    Net Volume: 140 lt

    Door hinges: 1 Left+1 Right

    External dimensions, Width: 955 mm

    External dimensions, Depth: 700 mm

    External dimensions, Height: 858 mm

    Depth with doors open: 1120 mm

    Gross capacity: 250 lt

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Supply voltage: 220-240 V/1 ph/50 Hz

  • Compressor power: 1/5 hp

  • Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 314 W

    Refrigerant weight: 50 g

    Energy Class (EU Reg. 2015/1094): C

    Yearly and daily energy consumption (EU Reg. 2015/1094): 853kWh/year - 2kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 39.51

Product Features

Main Features

Tropicalized unit.
Adjustable temperature range from 2 °C to 10 °C to suit meat, fish and dairy storage requirements.
Forced air circulation for rapid cooling and an even temperature distribution.
Automatic evaporation of defrost water. Prearrangement for drain outlet.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Digital control panel.
Anti-tilt runners accept GN 1/1 containers.
A kit of wheels is available as optional accessory for easier movement.

Sustainability

CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
50 mm insulation for energy saving.

Construction

IPX3 protected.
Access to all components from the front.
Built-in compressor to suit operating conditions.
Constructed from AISI 304 Stainless steel throughout to meet the highest hygiene standards.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Mounted on legs with height adjustment.
Rounded internal corners for ease of cleaning.
Adjustable feet 66-88 mm (see optional accessory).
