Digital Undercounter ecostore HP Concept Refrigerated Counter - 4 Drawers (R290) (COD 710460)

Compare Where to buy

ecostore HP Concept Refrigerated Counters - 2 comp. with top

Digital Undercounter
ecostore HP Concept Refrigerated Counter - 4 Drawers (R290)

COD 710460

4x1/2-drawer Refrigerated Counter, -2°+10°C, AISI 304 (R290)

Compare

Where to buy

Specifications

ISO Certificates

ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001
Electric

Supply voltage: 220-240 V/1 ph/50 Hz

Electrical power, max: 0.22 kW

Defrost Power: 0.2 kW

Plug type: CE-SCHUKO
Key Information

Net Volume: 124 lt

Door hinges:

External dimensions, Width: 1245 mm

External dimensions, Depth: 700 mm

External dimensions, Height: 900 mm

Internal Dimensions, Width: 798 mm

Internal Dimensions, Depth: 560 mm

Internal Dimensions, Height: 550 mm

Net weight: 104 kg

Shipping volume: 1.09 m³

Depth with doors open: 1110 mm

Height adjustment: 0/0 mm

Gross capacity: 290 lt
Refrigeration Data

Control type: Digital

Refrigeration power at evaporation temperature: -10 °C

Min/Max internal humidity: 40/85

Operating temperature min.: -2 °C

Operating temperature max.: 10 °C

Compressor power: 0.25 hp

Operating mode: Ventilated

Insulation: 90 mm (Cyclopentane)
Sustainability

Current consumption: 1.6 Amps

Refrigerant type: R290

GWP Index: 3

Refrigeration power: 358 W

Refrigerant weight (unit 1): 45 g

Energy Class (EU Reg. 2015/1094): A

Yearly and daily energy consumption (EU Reg. 2015/1094): 525kWh/year - 1kWh/24h

Climate class (EU Reg. 2015/1094): Normal duty (cl.4)

Energy Efficiency Index-EEI (EU Reg. 2015/1094): 24,92

Documents

Product Features

Main Features

Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.

Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.

Anti-tilt runners accept GN 1/1 containers.

Frontal and easy access to all components in the cooling unit.

Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.

Self closing stainless steel doors (< 90°).

Certified safety CE requirements.

Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).

Tropicalized unit.

Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.

Refrigerated compartment designed to accept GN 1/1 containers.

Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.

Digital control panel.

Forced air circulation for rapid cooling and an even temperature distribution.

Sustainability

Hot gas automatic evaporation of defrost water.

Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).

Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

User Interface & Data Management

Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.

Easy serviceability thanks to the intuitive control panel with access via app.

Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Construction

Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.

Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.

Interior base with rounded corners, pressed from a single sheet.

If needed, working top can be removed for easier handling during installation (in case of narrow doors).

Excellent space optimisation thanks to the compact dimensions.

External back panel in galvanized steel.

Developed and produced in ISO 9001 and ISO 14001 certified factory.

Internal dimension of the drawers.
• models with 2 1/2 drawers: 1st drawer (top drawer) 203x302x521 / 2nd drawer 223x302x521 (HxWxD)
• models with 3 1/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd and 3rd drawers 118x302x521 (HxWxD)
• models with 1/3+2/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd drawer 333x302x521 (HxWxD)

Extractable cooling unit to facilitate maintenance.

Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.

Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.

Fault code display.

Worktop in AISI 304 Stainless steel with a 50 mm profile.

Pre-arranged for drain-pipe.

External bottom panel in stainless steel.

Built-in refrigeration unit.

Anti-drip profile on stainless steel worktop edge.

Built-in compressor to suit operating conditions.

Constructed from AISI 304 Stainless steel throughout to meet the highest hygiene standards.

Rounded internal corners for ease of cleaning.

Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.

Access to all components from the front.
